HXGN2-12 box type fixed high-voltage switchgear

HXGN series switchgear (full name: indoor AC metal-enclosed ring network switchgear/Ring Main Unit) is a high-voltage switchgear suitable for ring network power supply and terminal power supply of distribution systems.

Classification:

Keywords

Retail price:

Market price:

Number:

h001

Weight:

Quantity

Remaining stock

加入购物车

立即购买

隐藏域元素占位

Field of application

Residence

Industry and commerce

Energy Storage

Photovoltaic power generation

Metal melting

State Grid

Product Introduction

HXGN series switchgear (full name: indoor AC metal-enclosed ring network switchgear) is a high-voltage switchgear suitable for ring network power supply and terminal power supply of distribution systems. It is mainly used for 10kV, 24kV, and 35kV voltage levels. It has the characteristics of compact structure, safety and reliability, and easy installation. It is widely used in urban distribution networks, industrial enterprises, commercial buildings, residential communities and other scenarios.

Technical Specification

Product Type	Indoor AC Metal-Enclosed Ring Network Switchgear
Design Standards	IEC 62271-200, IEEE C37.20.3
Rated Voltage	10kV / 24kV / 35kV
Frequency	50Hz / 60Hz
Rated Current	630A / 1250A / 1600A (Load Switch)
Short-Circuit Withstand	20kA/4s (25kA Optional)
Protection Class	IP4X (Internal), IP3X (External)
Mechanical Life	≥10,000 Operations (Breakers & Switches)

Features of Structure

Modular design
The metal enclosed box is composed of modules such as busbar room, switch room, cable room, etc. The layout is compact and the floor space is small, which is suitable for scenarios with limited space (such as box-type substations and underground distribution rooms).
It supports multiple circuit combinations (such as incoming lines, outgoing lines, and transformer feeder circuits), and can be flexibly expanded to meet the needs of different power distribution solutions.
Insulation and arc extinguishing technology
Insulation method: common air insulation (using insulating sleeves, heat shrinkable materials) or SF₆ gas insulation (some models). The new generation of products gradually uses environmentally friendly gases (such as N₂ mixed gas) to replace SF₆, which is in line with the global low-carbon and environmental protection trend.
Switch configuration: The main switch can be equipped with a load switch (with fuse) or a circuit breaker (such as a vacuum circuit breaker) to meet different short-circuit breaking capacity requirements. The load switch + fuse combination solution combines economy and protection functions, and is suitable for transformer protection scenarios.
Safety interlock system
It has "five-protection" interlocking function (preventing accidental opening and closing of switches, preventing the closing of switches with load, preventing the hanging of ground wires with power on, preventing the closing of switches with ground wires, and preventing the accidental entry into the live interval), and ensures safe operation through mechanical or electrical interlocking.
The cabinet door is linked to the switch status and cannot be opened when powered on, ensuring the safety of operation and maintenance personnel.
Maintenance-free and high reliability
The air-insulated type does not require gas maintenance, and the SF₆ type adopts a fully sealed structure with low gas leakage rate and long maintenance cycle (usually 10-15 years).
It can adapt to wide temperature environment (-25℃~+55℃), with protection level up to IP3X/IP4X, moisture-proof, dust-proof, and anti-condensation, suitable for outdoor box transformers or humid environments.

Functions

◊Ring network power supply: supports multi-node ring networking, and can be isolated through segmented switches in case of faults, improving power supply reliability and reducing the scope of power outages.
◊Distribution protection: overload and short-circuit protection is achieved through fuses or circuit breakers, and faults are quickly removed to ensure system safety.
◊Flexible wiring: supports cable entry and exit, adapts to different cable specifications, and can be integrated with transformers, lightning arresters, mutual inductors and other equipment.

If you need specific model selection recommendation or customized solutions, please contact us for technical support.
